MSI MAG B560 Tomahawk WiFi Intel 10th Gen and 11th Gen ATX Motherboard

Out Of Stock

MSI MAG B560 Tomahawk WiFi Intel 10th Gen and 11th Gen ATX Motherboard

Stock: Out Of Stock
Model: MSI MAG B560 Tomahawk WiFi
Product id: 19631

Based on 0 reviews. - Write a review

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Add to Compare

• Supports 10th & 11th Gen Processors • DDR4 Memory, up to 5066(OC) MHz • Extended Heatsink Design & M.2 Shield Frozr • 2.5G LAN and Intel Wi-Fi 6E Solution

যেকোনো অনাকাঙ্ক্ষিত ঝামেলা এড়াতে, অনলাইনে অর্ডার করার আগে আমাদের হেল্পলাইনে (+8801612-266507) কল করে পণ্যের স্টক এবং ডেলিভারি সম্পর্কে জেনে নেওয়ার জন্য বিনীত অনুরোধ করা হচ্ছে।

Key Features
Form Factor	ATX
Basic Information
Supported CPU	10th Gen, Pentium Gold, Celeron, 11th Gen
Chipset	Intel B560
Memory
Ram Type	DDR4

MSI MAG B560 Tomahawk WiFi Intel 10th Gen and 11th Gen ATX Motherboard

MSI MAG B560 Tomahawk WiFi ATX Motherboard supports 10th Gen Intel Core, 11th Gen Intel Core, Pentium Gold and Celeron processors for LGA 1200 socket, DDR4 Memory, up to 5066(OC) MHz, Lightning M.2: Running at PCIe Gen4 x4 maximizes performance for NVMe based SSDs, Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works. This Motherboard comes with 2.5G LAN and Intel Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use.

This MSI MAG B560 Tomahawk WiFi Intel 10th Gen and 11th Gen ATX Motherboard has 03 years warranty.

Specifications:

Basic Information
Supported CPU	Supports 10th Gen Intel Core Processors, 11th Gen Intel Core Processors, Pentium Gold and Celeron Processor socket LGA1200
Chipset	Intel B560 Chipset
Form Factor	ATX
Audio	7.1-Channel High Definition Audio Supports S/PDIF output
Expansion Slots
PCI	2x PCIe x16 slots PCI_E1 (from CPU) Support up to PCIe 4.0 for 11th Gen Intel CPU Support up to PCIe 3.0 for 10th Gen Intel CPU PCI_E2 (from B560 chipset) Support up to PCIe 3.0 x4 1x PCIe 3.0 x1 slot (from B560 chipset)
M.2 Socket	3x M.2 slots (Key M)
Memory
Type	DDR4
Slots	4 x DDR4 memory slots
Supported Memory	- 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel CPU (by JEDEC & POR) - 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel CPU (by JEDEC & POR) - Max overclocking frequency: - 1DPC 1R Max speed up to 5066 MHz - 1DPC 2R Max speed up to 4600+ MHz - 2DPC 1R Max speed up to 4266+ MHz - 2DPC 2R Max speed up to 4000+ MHz - Dual-Channel mode - non-ECC, un-buffered memory - Intel Extreme Memory Profile (XMP)
Maximum Mamory	up to 128GB
Graphics
Graphics	1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz
Connector & Ports
USB (s)	- 1x USB3.2 Gen 2x2 20Gbps port (Type-C port on the back panel) - 1x USB 3.2 Gen 2 10Gbps port (1 Type-C available through the internal connector) - 6x USB 3.2 Gen 1 5Gbps ports (4 Type-A ports on the back panel, 2 Type-A ports available through the internal connector) - 4x USB 2.0 ports on the back panel Hub-GL850G - 4x USB 2.0 ports available through the internal connectors
LAN Port (s)	1x Realtek RTL8125B 2.5Gbps LAN controller
Supported Storage	- 6x SATA 6Gb/s ports (from B560 chipset) 1 - 3x M.2 slots (Key M) - M2_1 slot (from CPU) - Available only on 11th Gen Intel CPU - Supports up to PCIe 4.0 x4 - Supports 2242/ 2260/ 2280/ 22110 storage devices -M2_21 slot (from B560 chipset) - up to PCIe 3.0 x4 - SATA up to 6Gb/s - 2242/ 2260/ 2280 storage devices - M2_3 slot (from B560 chipset) - Supports up to PCIe 3.0 x4 - Supports 2242/ 2260/ 2280 storage devices - Intel Optane Memory Ready2 - Supports Intel Smart Response Technology for Intel Core processors
Audio	7.1-Channel High Definition Audio Supports S/PDIF output
Internal I/O Ports	24-pin ATX main power connector 8-pin ATX 12V power connector 4-pin ATX 12V power connector 6-pin PCIE power connector 6x SATA 6Gb/s connectors 3x M.2 slots (M-Key) 1x USB 3.2 Gen 2 10Gbps Type-C port 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin water-pump fan connector 5x 4-pin system fan connectors 1x Front panel audio connector 2x System panel connectors 1x Chassis Intrusion connector 1x Clear CMOS jumper TPM module connector 1x TBT connector (supports RTD3) 1x Tuning Controller connector
Warranty Information
Manufacturing Warranty	03 years warranty
