Gigabyte X299 AORUS Gaming 7 Motherboard

Out Of Stock

Stock: Out Of Stock
Model: Model-4885
Product id: 17425

Based on 0 reviews. - Write a review

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

* অনলাইনে প্রোডাক্ট অর্ডারের পূর্বে আমাদের হেল্পলাইন +8801612-266507 নম্বরে কল দিয়ে স্টক এবং ডেলিভারী সর্ম্পকে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা যাচ্ছে *

• Model: X299 AORUS Gaming 7 • Supports Intel® Core™ X-series Processor Family • DDR4, 8 DIMMs, DDR4400+(OC) • Intel® Optane™ Memory Ready • Intel® VROC ready

Gigabyte X299 AORUS Gaming 7 Motherboard

Supports Intel® Core™ X-series Processor Family
Quad Channel Non-ECC Unbuffered DDR4, 8 DIMMs, DDR4400+(OC)
Intel® Optane™ Memory Ready
Intel® VROC ready
ASMedia 3142 USB 3.1 Gen 2 with USB Type-C™ and Type-A
Front USB 3.1 Gen 2 Header
3-Way Graphics Support with Dual Armor and Ultra Durable™ Design
Server-Class Digital Power Design
121dB SNR AMP-UP Audio with ALC1220 & High-End ESS SABRE 9018 DAC with WIMA audio capacitor
Sound BlasterX 720°, the top-of-the-line audio engine solution for 4K gaming and entertainment
Killer DoubleShot™ Pro for the best gaming networking experience possible
Killer 2x2 802.11ac Wireless – AC 1535
Intel® GbE LAN Gaming Network
RGB FUSION with Multi-Zone Digital LED Light Show design, support digital LED & RGB LED strips
Swappable Overlay for Accent LED
Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
Triple Ultra-Fast M.2 with PCIe Gen3 x4 interface and Thermal Guard
NVMe PCIe Gen3 x4 U.2 support by optional adaptor
USB DAC-UP 2 with Adjustable Voltage
Precise Digital USB Fuse Design for Stronger Protection
Anti-Sulfur Resistor Design
Ultra Durable™ 25KV ESD and 15KV Surge LAN Protection
Lightning-Fast Intel® Thunderbolt™ 3 AIC Support
GIGABYTE UEFI DualBIOS™ with Q-Flash Plus USB port
APP Center Including EasyTune™ and Cloud Station™ Utilities

Specification:

Motherboard
Chipset	Intel® X299 Express Chipset
Supported Processors	Support for Intel® Core™ X series processors in the LGA2066 package L3 cache varies with CPU
Max Memory	8 x DDR4 DIMM sockets supporting up to 128 GB of system memory. * Support for up to 512 GB of system memory when using Registered DIMMs. * Supported when using a 44-lane or 28-lane CPU (6-core or above). 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory. * Supported when using a 16-lane CPU (4-core). 4 channel memory architecture. * Supported when using a 44-lane or 28-lane CPU (6-core or above). Dual channel memory architecture. Supported when using a 16-lane CPU (4-core). Support for DDR4 4400(O.C.) / 4333(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400 / 2133 MHz memory modules Support for non-ECC Un-buffered DIMM memory modules Support for Registered DIMM 1Rx8/2Rx8/1Rx4/2Rx4 memory modules (operate in non-ECC mode) Support for Extreme Memory Profile (XMP) memory modules
Onboard Video	1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe x4/x2 SSD support) (M2P_32G) 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe x4/x2 SSD support) (M2M_32G) 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2Q_32G) 8 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, RAID 5, and RAID 10 * The M2M_32G connector must work with an Intel® VROC Upgrade Key to support RAID configuration. * Refer to "1-10 Internal Connectors," for the installation notices for the M.2 and SATA connectors. Intel® Optane™ Memory Ready Intel® VROC ready Multi-Graphics Technology Support for NVIDIA® Quad-GPU SLI™ and 3-Way* /2-Way NVIDIA® SLI™ technologies * Supported when using a 44-lane or 28-lane CPU. Support for AMD Quad-GPU CrossFire™ and 3-Way* /2-Way AMD CrossFire™ technologies * Supported when using a 44-lane or 28-lane CPU.
Onboard Audio	Realtek® ALC1220 codec ES9018Q2C chip Support for Sound BlasterX 720° High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out
Peripheral interfaces	Chipset+2 ASMedia® USB 3.1 Gen 2 Controllers: 1 x USB 3.1 Gen 2 port available through the internal USB header 1 x USB Type-C™ port on the back panel, with USB 3.1 Gen 2 support Chipset+Realtek® USB 3.1 Gen 2 Hub: 4 x USB 3.1 Gen 2 Type-A ports (red) on the back panel Chipset+Realtek® USB 3.1 Gen 1 Hub: 4 x USB 3.1 Gen 1 ports on the back panel Chipset: 4 x USB 3.1 Gen 1 ports available through the internal USB headers 4 x USB 2.0/1.1 ports available through the internal USB headers Internal I/O Connectors 1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x water cooling CPU fan header 4 x system fan headers 1 x system fan/water cooling pump header 1 x 3 Amp fan/water cooling pump header 1 x I/O shield audio LED power connector 1 x digital LED strip extension cable header 2 x RGB (RGBW) LED strip extension cable headers 3 x M.2 Socket 3 connectors 8 x SATA 6Gb/s connectors 1 x Intel® VROC Upgrade Key header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB 3.1 Gen 2 header 2 x USB 3.1 Gen 1 headers 2 x USB 2.0/1.1 headers 1 x Thunderbolt™ add-in card connector 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x power button 1 x reset button 1 x Clear CMOS button 1 x ECO button 1 x OC button 2 x temperature sensor headers Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x USB Type-C™ port, with USB 3.1 Gen 2 support 4 x USB 3.1 Gen 2 Type-A ports (red) 4 x USB 3.1 Gen 1 ports 2 x RJ-45 ports 2 x MMCX antenna connectors (2T2R) 1 x optical S/PDIF Out connector 5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In) I/O Controller iTE® I/O Controller Chip
Onboard LAN	1 x Intel® GbE LAN chip (10/100/1000 Mbit) (LAN1) 1 x Rivet Networks Killer™ E2500 LAN chip (10/100/1000 Mbit) (LAN2)
Warranty	3 Years
