Asus ROG STRIX Z790-H GAMING WIFI DDR5 13th Gen ATX Motherboard

Specification

Key Features
Supported CPU	Intel Socket LGA1700 For 13th Gen Intel Core™ & 12th Gen Intel® Core, Pentium Gold And Celeron Processors Supports Intel Turbo Boost Technology 2.0 And Intel Turbo Boost Max Technology 3.0
Chipset	Intel Z790 Chipset
Memory	7800+(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 Non-ECC, Un-Buffered Memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) OptiMem II
Graphics	1 X DisplayPort (Supports Max. 8K@60Hz As Specified In DisplayPort 1.4) 1 X HDMI Port (Supports 4K@60Hz As Specified In HDMI 2.1)
Slots	4 X DIMM
Supported Storage	Total Supports 2 X M.2 Slots And 4 X SATA 6Gb/S Ports Intel W480 Chipset: 1 X M.2 Socket 3, With M Key, Type 2242/2260/2280/22110 Storage Devices Support (SATA & PCIE 3.0 X 4 Mode)*3 1 X M.2 Socket 3, With M Key, Type 2242/2260/2280/22110 Storage Devices Support (SATA & PCIE 3.0 X 4 Mode)*4 6 X SATA 6Gb/S Port(S) Support Raid 0, 1, 5, 10 Intel Rapid Storage Technology Supports Intel Optane Memory Ready
USB Port	Rear USB (Total 10 Ports) 1 X USB 3.2 Gen 2x2 Port (1 X USB Type-C) 3 X USB 3.2 Gen 2 Ports (2 X Type-A + 1 X USB Type-C) 4 X USB 3.2 Gen 1 Ports (4 X Type-A) 2 X USB 2.0 Ports (2 X Type-A) Front USB (Total 7 Ports) 1 X USB 3.2 Gen 2x2 Connector (Supports USB Type-C) 1 X USB 3.2 Gen 1 Header Supports 2 Additional USB 3.2 Gen 1 Ports 2 X USB 2.0 Headers Support 4 Additional USB 2.0 Ports
Internal I/O Ports	Fan And Cooling Related 1 X 4-Pin CPU Fan Header 1 X 4-Pin CPU OPT Fan Header 1 X 4-Pin AIO Pump Header 5 X 4-Pin Chassis Fan Headers Power Related 1 X 24-Pin Main Power Connector 2 X 8-Pin +12V Power Connectors Storage Related 4 X M.2 Slots (Key M) 4 X SATA 6Gb/S Ports USB 1 X USB 3.2 Gen 2x2 Connector (Supports USB Type-C) 1 X USB 3.2 Gen 1 Header Supports 2 Additional USB 3.2 Gen 1 Ports 2 X USB 2.0 Headers Support 4 Additional USB 2.0 Ports Miscellaneous 3 X Addressable Gen 2 Headers 1 X Aura RGB Header 1 X CPU Over Voltage Jumper 1 X Front Panel Audio Header (AAFP) 1 X 20-3 Pin System Panel Header With Chassis Intrude Function 1 X Thermal Sensor Header 1 X Thunderbolt Header Back Panel I/O Ports 1 X USB 3.2 Gen 2x2 Port (1 X USB Type-C) 3 X USB 3.2 Gen 2 Ports (2 X Type-A + 1 X USB Type-C) 4 X USB 3.2 Gen 1 Ports (4 X Type-A) 2 X USB 2.0 Ports (2 X Type-A) 1 X DisplayPort 1 X HDMI Port 1 X Wi-Fi Module 1 X Intel 2.5Gb Ethernet Port 5 X Gold-Plated Audio Jacks 1 X Optical S/PDIF Out Port 1 X BIOS FlashBack Button 1 X Clear CMOS Button
Form Factor	ATX Form Factor 12 Inch X 9.6 Inch ( 30.5 Cm X 24.4 Cm )
BIOS	256 Mb Flash ROM, UEFI AMI BIOS
Others	ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC S1220A - Impedance Sense For Front And Rear Headphone Outputs - Supports: Jack-Detection, Multi-Streaming, Front Panel Jack-Retasking - High Quality 120 DB SNR Stereo Playback Output And 113 DB SNR Recording Input - Supports Up To 32-Bit/192 KHz Playback Audio Features - SupremeFX Shielding Technology - Savitech SV3H712 AMP - Rear Optical S/PDIF Out Port - Premium Audio Capacitors - Audio Cover
Warranty	3 Years

Asus ROG STRIX Z790-H GAMING WIFI DDR5 Motherboard

The ASUS ROG STRIX Z790-H GAMING WIFI DDR5 12th & 13th Gen ATX Motherboard is a top-of-the-line motherboard designed for gamers and enthusiasts looking to build a high-performance PC. It is equipped with an Intel LGA 1700 socket, making it ready for use with 13th-generation Intel Core and 12th-generation Intel Core, Pentium Gold, and Celeron processors. The motherboard features a robust power solution with 16 + 1 power stages rated for 80A, dual ProCool II power connectors, high-quality alloy chokes, and durable capacitors, providing stable power to support the latest multicore processors. It also boasts optimized VRM thermals with massive heat sinks connected by an L-shaped heat pipe, high-conductivity thermal pads, and an integrated I/O shroud. With four PCIe 4.0 M.2 slots all with heatsinks, including the tallest having a combo sink extension and backplate for additional cooling, the motherboard provides extensive M.2 support. Additionally, it offers abundant connectivity with a USB 3.2 Gen 2x2 Type-C rear I/O port and additional front panel connector, seven USB 3.2 Gen 2 and Gen 1 ports, PCIe 5.0 x16 SafeSlot, HDMI 2.1, and DisplayPort 1.4. The motherboard is equipped with built-in WiFi 6E (802.11ax) and 2.5Gb Intel Ethernet with ASUS LANGuard for high-performance networking. It also features intelligent control with ASUS-exclusive AI overclocking, AI II cooling, AI networking, and bi-directional AI noise cancellation to simplify setup and improve performance.
