MSI Intel B460M-A Pro 10th Gen Intel Motherboard

Out Of Stock

MSI Intel B460M-A Pro 10th Gen Intel Motherboard

Stock: Out Of Stock
Model: MSI Intel B460M-A Pro
Product id: 18065

Based on 0 reviews. - Write a review

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

* অনলাইনে প্রোডাক্ট অর্ডারের পূর্বে আমাদের হেল্পলাইন +8801612-266507 নম্বরে কল দিয়ে স্টক এবং ডেলিভারী সর্ম্পকে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা যাচ্ছে *

• Supports 10th Gen Intel Core / Pentium Celeron processors • M.2 Shield Frozr & Core Boost • Supports up to 2933MHz (Max) RAM • Turbo M.2, Audio Boost & Steel Armor

Key Features
Form Factor	mATX
Basic Information
Supported CPU	10th Gen, Pentium Gold, Celeron
Chipset	Intel B460
Memory
Ram Type	DDR4

MSI Intel B460M-A Pro 10th Gen Intel Motherboard

PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity. The world’s fastest SSDs can start to lower performance when getting hot. Part of the motherboards heatsink design, M.2 SHIELD FROZR is the next generation M.2 thermal solution to avoid this by offering the best thermal protection to make sure that SSD maintains maximum performance. MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you to check your primary system characteristics in a simplified graphical interface.

Specification:

Basic Information
Supported CPU	Supports 10th Gen Intel Core and Pentium Gold / Celeron processors for LGA 1200 socket
Chipset	Intel B460
BIOS	1x 128 Mb flash UEFI AMI BIOS Multi-language
Form Factor	Miro-ATX Form Factor 9.3 in. x 7.6 in. (23.6 cm x 19.2 cm)
Expansion Slots
PCI	1x PCIe 3.0 x16 slot 2x PCIe 3.0 x1 slots
M.2 Socket	1x M.2 slot (Key M) Supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280 storage devices
Memory
Type	Dual-Channel Architecture
Slots	2x DDR4 memory slots
Supported Memory	Intel Core i7/ i9 Supports up to DDR4 2933 MHz Intel Core i5 and below up to DDR4 2666 MHz non-ECC, un-buffered memory Intel Extreme Memory Profile (XMP)
Maximum Mamory	64GB
Graphics
Graphics	1x DVI-D port, supports a maximum resolution of 1920x1200 @60Hz 1x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @30Hz
Max Shared Memory	1GB
Connector & Ports
HDMI	1x HDMI 1.4 port, maximum resolution of 4096x2160 @30Hz
USB (s)	Intel B460 Chipset 6x USB 3.2 Gen 1 5Gbps ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 3.2 Gen 1 5Gbps connector) 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors)
LAN Port (s)	1x Realtek 8111H Gigabit LAN controller
Supported Storage	Intel B460 Chipset 6x SATA 6Gb/s ports 1x M.2 slot (Key M) Supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280 storage devices Intel Optane Memory Ready Supports Intel Smart Response Technology for Intel Core processors
Audio	Realtek ALC892 Codec 7.1-Channel High Definition Audio
Internal I/O Ports	1x 24-pin ATX main power connector 1 8-pin ATX 12V power connector 6x SATA 6Gb/s connectors 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1 USB 3.2 Gen1 5Gbps connector (supports additional 2 USB 3.2 Gen1 5Gbps ports) 1x 4-pin CPU fan connector 1 4-pin system fan connector 1x Front panel audio connector 2x Front panel connectors 1x TPM module connector 1 Serial port connector 1x Chassis Intrusion connector 1x Clear CMOS jumper 4x EZ Debug LED
DVI-D (s)	1x DVI-D port, maximum resolution of 1920x1200 @60Hz
Warranty Information
Manufacturing Warranty	03 Years Warranty
Others
Special Features	Intel B460 Chipset Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA storage devices
