MSI B850M GAMING PLUS WIFI6E AM5 mATX Motherboard
- Stock: In Stock
- Model: B850M GAMING PLUS WIFI6E
- Product id: 28602
- Supported RAM: 4x DDR5, up to 8200 (OC) MT/s
- Supported CPU: Ryzen 9000/ 8000/ 7000 Series Processors for Socket AM5
- Graphics Output: 1x HDMI, 1x DisplayPort
- Features: Realtek 8125D 2.5G LAN, Wi-Fi 6E, Bluetooth 5.3
| Basic Information | |
| Supported CPU | Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors Socket AM5 |
| Chipset | AMD B850 |
| BIOS | Flash BIOS Button |
| Form Factor | mATX 243.84mmx243.84mm |
| Audio | Realtek ALC897 7.1-Channel High Definition Audio |
| Expansion Slots | |
| PCI | 1x PCI-E x16 slot 2x PCI-E x1 slot PCI_E1 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E2 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E2 slot Supports PCIe 4.0 x16 (For Ryzen™ 9000/ 7000 Series processors) Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors) Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor) |
| M.2 Socket | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G M2_1 slot Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors) Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors) M2_2 slot Supports up to PCIe 4.0 x4 (For Ryzen™ 9000/ 8700/ 8600/ 8400/ 7000 Series processors) Supports up to PCIe 4.0 x2 (For Ryzen™ 8500/ 8300 Series processors) |
| Memory | |
| Slots | 4 x UDIMM |
| Supported Memory | Memory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen 9000 Series Processors max. overclocking frequency: 1DPC 1R Max speed up to 8200+ MT/s 1DPC 2R Max speed up to 6400+ MT/s 2DPC 1R Max speed up to 6400+ MT/s 2DPC 2R Max speed up to 6000+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPOTM Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory |
| Graphics | |
| Graphics | 1x HDMI Support HDMI 2.1, maximum resolution of 4K 60Hz 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz |
| Connector & Ports | |
| HDMI | 1x HDMI 2.1 |
| Display Port (s) | 1x DisplayPort 1.4 |
| USB (s) | 4x USB 2.0 (Front) 4x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 3x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear) 1x USB 10Gbps Type C (Front) |
| LAN Port (s) | Realtek 8125D 2.5G LAN |
| Wireless Communication module | Wi-Fi 6E Solution The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.3, FIPS, FISMA |
| Supported Storage | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G M2_1 slot Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 Series processors) Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series processors) M2_2 slot Supports up to PCIe 4.0 x4 (For Ryzen™ 9000/ 8700/ 8600/ 8400/ 7000 Series processors) Supports up to PCIe 4.0 x2 (For Ryzen™ 8500/ 8300 Series processors) |
| RAID | Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices Supports RAID 0 and RAID 1 for M.2 NVMe storage devices |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 3x System Fan 1x EZ Conn-header (JAF_1) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports |
| Warranty Information | |
| Warranty | 3 Years |
MSI B850M GAMING PLUS WIFI6E AM5 mATX Motherboard
The MSI B850M GAMING PLUS WIFI6E AM5 mATX Motherboard is a powerhouse built for modern AMD Ryzen desktop processors. Supporting Ryzen 9000, 8000, and 7000 Series CPUs with Socket AM5, this motherboard offers unbeatable compatibility and performance for gamers and content creators alike. Powered by the AMD B850 chipset, it delivers top-tier reliability and stability.
It supports DDR5 memory up to 256GB, with speeds reaching an incredible 8200+ MT/s (OC), ideal for multitasking and demanding workloads. With dual M.2 slots, including PCIe 5.0 x4 and PCIe 4.0 x4, along with 4x SATA 6Gb/s ports, you’ll enjoy ultra-fast storage and seamless data transfer. The Realtek 8125D 2.5G LAN and Wi-Fi 6E offer high-speed networking for lag-free online gaming and streaming.
Expansion options include 1x PCIe x16 and 2x PCIe x1 slots, supporting advanced GPUs and add-on cards. The motherboard also features HDMI 2.1 and DisplayPort 1.4, supporting 4K displays at 60Hz for vivid visuals. It’s packed with USB options—USB 10Gbps Type-C, USB 5Gbps, and USB 2.0 ports—ensuring full peripheral compatibility. The 7.1-channel HD audio, powered by Realtek ALC897, delivers immersive sound quality for a premium gaming experience.
With features like EZ Debug LED, TPM 2.0 support, multiple RGB connectors, and a 3-year warranty, the MSI B850M GAMING PLUS WIFI6E is the perfect choice for gamers looking to build a future-ready AM5 gaming PC without breaking the bank. Buy the MSI B850M GAMING PLUS Motherboard in Bangladesh now at the best price and take your gaming performance to the next level!
