GIGABYTE B760 GAMING X AX ATX Motherboard

Name: GIGABYTE B760 GAMING X AX ATX Motherboard
Brand: GIGABYTE
Price: 22.00 BDT
Availability: InStock

Save: 2821৳ (11%)

GIGABYTE B760 GAMING X AX ATX Motherboard

Stock: In Stock
Model: B760 GAMING X AX
Product id: 26580

Based on 0 reviews. - Write a review

22,899৳

25,720৳

Ex Tax: 22,899৳

EMI starts at 8,030৳/month. View all 25 banks EMI plans >

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

* অনলাইনে প্রোডাক্ট অর্ডারের পূর্বে হেল্পলাইন থেকে স্টক এবং ডেলিভারী সর্ম্পকে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা যাচ্ছে *

Supported CPU: 14th/13th/12th Gen Intel Processors (LGA1700)
Supported RAM: 4x DDR5, Max 192GB 7600(OC)
Features: 2.5GbE LAN & Wi-Fi 6E 802.11ax
Graphics Output: 1x HDMI, 1x DisplayPort

Basic Information
Supported CPU	LGA1700 socket: Support for the 14th, 13th and 12th Generation Intel Core, Pentium Gold and Celeron Processors L3 cache varies with CPU
Chipset	Intel B760 Express Chipset
BIOS	1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	ATX Form Factor; 30.5cm x 24.4cm
Audio	Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out
Expansion Slots
PCI	CPU: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1, PCIEX1_2)
Memory
Type	DDR5
Slots	4
Supported Memory	Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules
Maximum Memory	192GB
Graphics
Graphics	Integrated Graphics Processor-Intel HD Graphics support: 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 1.2 version and HDCP 2.3 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.0 version and HDCP 2.3.
Connector & Ports
HDMI	1x HDMI
Display Port (s)	1x DisplayPort
USB (s)	Chipset: 1 x USB Type-C port with USB 3.2 Gen 2 support, available through the internal USB header 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel 1 x USB Type-C port on the back panel, with USB 3.2 Gen 1 support 3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through the internal USB header) 1 x USB 2.0/1.1 port on the back panel Chipset+2 USB 2.0 Hubs: 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
LAN Port (s)	Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless Communication module	AMD Wi-Fi 6E RZ608 (MT7921K) (PCB rev. 1.0) WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.2 Support for 11ax 80MHz wireless standard and up to 1.2 Gbps data rate Intel Wi-Fi 6E AX210 (PCB rev. 1.1) WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.3 Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate Intel Wi-Fi 6E AX211 (PCB rev. 1.2) WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.3 Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate Realtek Wi-Fi 6E RTL8852CE (PCB rev. 1.3) WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.3 Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
Supported Storage	CPU: 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: 2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2M_SB) 4 x SATA 6Gb/s connectors
RAID	RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
TPM (Trusted Platform Module )	1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
Audio	6 x audio jacks
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x CPU fan/water cooling pump header 3 x system fan headers 1 x system fan/water cooling pump header 2 x addressable LED strip headers 2 x RGB LED strip headers 3 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB Type-C® header, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x serial port header 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper
Others
Special Features	Support for GIGABYTE Control Center (GCC) Support for Q-Flash Support for Q-Flash Plus
Bundled Software	Norton Internet Security (OEM version) LAN bandwidth management software
Warranty Information
Warranty	3 years

GIGABYTE B760 GAMING X AX ATX Motherboard

GIGABYTE B760 GAMING X AX ATX Motherboard is a versatile and robust platform designed to cater to the needs of gamers and high-performance PC builders. It features the LGA1700 socket, making it compatible with the latest 14th, 13th, and 12th Generation Intel Core processors, along with Pentium Gold and Celeron processors. This ensures that users have access to the latest advancements in processing power, offering superior performance and efficiency for a wide range of applications. One of the standout features of this motherboard is its support for DDR5 memory, providing faster speeds and improved performance compared to previous generations. The B760 GAMING X AX supports a wide range of overclocked memory modules, up to DDR5 7600(O.C.), ensuring that users can push their systems to the limit. With four memory slots and a maximum capacity of 192GB, the motherboard offers ample room for memory expansion, catering to the needs of power users and content creators who require substantial memory resources. In terms of graphics, the motherboard supports Intel's integrated graphics processors, featuring both a DisplayPort and an HDMI port. These ports support high resolutions of up to 4096x2304@60Hz and 4096x2160@60Hz, respectively, ensuring sharp and vibrant visuals for gaming and multimedia applications. Expansion capabilities are another strong suit of the GIGABYTE B760 GAMING X AX. It includes one PCI Express x16 slot for a graphics card, which supports PCIe 4.0 for optimal performance. Additionally, it has two PCI Express x16 slots running at x1 for other expansion cards, providing flexibility for additional peripherals. Storage options on the motherboard are comprehensive, featuring one M.2 connector from the CPU supporting PCIe 4.0 x4 SSDs and two M.2 connectors from the chipset, also supporting PCIe 4.0 x4 SSDs. Alongside these, there are four SATA 6Gb/s connectors for traditional HDDs and SSDs, supporting RAID 0, RAID 1, RAID 5, and RAID 10 configurations for enhanced data performance and redundancy. Networking and connectivity are top-notch with the inclusion of Realtek 2.5GbE LAN for fast wired connections and multiple options for Wi-Fi 6E support, depending on the PCB revision. The various Wi-Fi modules (AMD, Intel, and Realtek) offer high-speed wireless connectivity and Bluetooth support, ensuring seamless network performance and device pairing. The motherboard also features a rich set of internal I/O ports, including multiple fan headers, LED strip headers, and USB headers, ensuring that users can fully customize their builds with advanced cooling solutions and RGB lighting. Special features like GIGABYTE Control Center, Q-Flash, and Q-Flash Plus add to the convenience, allowing for easy system management and firmware updates. Overall, the GIGABYTE B760 GAMING X AX ATX Motherboard stands out as a powerful and versatile choice for gamers and PC enthusiasts, offering robust performance, extensive connectivity options, and ample expansion capabilities.
