GIGABYTE B760M D3HP WIFI6 Micro ATX Motherboard

Name: GIGABYTE B760M D3HP WIFI6 Micro ATX Motherboard
Brand: GIGABYTE
Price: 18.00 BDT
Availability: InStock

Save: 1000৳ (5%)

GIGABYTE B760M D3HP WIFI6 Micro ATX Motherboard

Stock: In Stock
Model: B760M D3HP WIFI6
Product id: 28945

Based on 0 reviews. - Write a review

18,500৳

19,500৳

Ex Tax: 18,500৳

EMI starts at 6,487৳/month. View all 25 banks EMI plans >

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

* অনলাইনে প্রোডাক্ট অর্ডারের পূর্বে হেল্পলাইন থেকে স্টক এবং ডেলিভারী সর্ম্পকে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা যাচ্ছে *

Supported CPU: 13th/12th Gen Intel Processors (LGA1700)
Supported RAM: 4x DDR4, Max 128GB 5333 MHz (OC)
Connectivity: Wi-Fi 6, 2.5 GbE LAN, Bluetooth 5.2
Graphics Output: 1x HDMI, 1x DisplayPort, Realtek Audio Codec

Basic Information
Bundled Software	Norton® Internet Security (OEM version) LAN bandwidth management software
CPU	LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors (Go to GIGABYTE's website for the latest CPU support list.) L3 cache varies with CPU
Onboard Graphics	Integrated Graphics Processor-Intel® HD Graphics support: - 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. ** Support for native HDMI 2.1 TMDS compatible ports. - 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 1.2 version and HDCP 2.3 (Graphics specifications may vary depending on CPU support.) Support for up to triple-display at the same time
Operating System	Support for Windows 11 64-bit Support for Windows 10 64-bit
Memory	4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)
Chipset	Intel® B760 Express Chipset
BIOS	1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	Micro ATX Form Factor; 24.4cm x 24.4cm
Audio	Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out
Connector & Ports
USB (s)	Chipset: - 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header - 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) - 2 x USB 2.0/1.1 ports on the back panel Chipset+USB 2.0 Hub: - 4 x USB 2.0/1.1 ports available through the internal USB headers
LAN Port (s)	Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Wireless Communication module	Realtek® Wi-Fi 6 RTL8851BE - WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands - BLUETOOTH 5.3 - Support for 11ax 80MHz wireless standard (Actual data rate may vary depending on environment and equipment.)
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 3 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/ GC-TPM2.0 SPI V2 module only) 1 x serial port header 1 x parallel port header 1 x S/PDIF Out header 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper --------- Back Panel Connectors 2 x USB 2.0/1.1 ports 1 x PS/2 keyboard/mouse port 2 x SMA antenna connectors (1T1R) 1 x D-Sub port* 1 x DisplayPort* 1 x HDMI port* 3 x USB 3.2 Gen 1 ports 1 x RJ-45 port 3 x audio jacks
External Features
Storage Interface	CPU: - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) - 4 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Expansion Slots	CPU: - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 * The PCIEX16 slot can only support a graphics card or an NVMe SSD. Chipset: - 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1
I/O Port	iTE® I/O Controller Chip
Warranty Information
Warranty	3 Years

GIGABYTE B760M D3HP WIFI6 Micro ATX Motherboard

GIGABYTE B760M D3HP WIFI6 Micro ATX Motherboard Price in bd makes it one of the most versatile and high-performance choices for gamers, content creators, and PC enthusiasts in Bangladesh. This Micro ATX motherboard is designed for 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold, and Celeron® processors, providing robust support through its LGA1700 socket. With the Intel® B760 Express chipset, it ensures smooth multitasking, high-speed data transfer, and stable system performance. The motherboard supports up to 192GB DDR5 memory across 4 DIMM slots, offering extreme memory profile (XMP) compatibility and dual-channel architecture for seamless performance. Integrated Intel® HD graphics support triple-display setups through HDMI 2.1, DisplayPort 1.2, and D-Sub ports, delivering stunning visuals for gaming and productivity. High-definition audio via Realtek® Audio CODEC ensures immersive sound for movies, games, and music. Connectivity is enhanced with Realtek® Wi-Fi 6, Bluetooth 5.3, and 2.5 GbE LAN for ultra-fast internet and low-latency networking. Storage options include two M.2 PCIe 4.0 slots, four SATA 6Gb/s ports, and RAID support for flexible and high-speed data management. USB connectivity is versatile with Type-C, USB 3.2 Gen 1, and multiple USB 2.0 ports. Additional features such as Q-Flash Plus, GIGABYTE Control Center, addressable RGB headers, and multiple fan headers make system customization and thermal management easier. The Micro ATX form factor ensures compatibility with a wide range of PC cases. Ideal for both professionals and gamers, the GIGABYTE B760M D3HP WIFI6 combines cutting-edge technology, speed, and stability, making it a top motherboard choice in Bangladesh for those seeking premium performance at an affordable price.

Availability and Usability

The GIGABYTE B760M D3HP WIFI6 Micro ATX Motherboard is readily available in Bangladesh through top retailers. Its user-friendly BIOS, multiple connectivity options, and Micro ATX form factor make installation and system upgrades effortless. Perfect for gamers, content creators, and PC builders, this motherboard ensures reliable performance and compatibility with the latest Intel processors.

Features:

Advanced DDR5 memory support with up to 192GB capacity ensures ultra-fast multitasking and smooth gaming performance.
Integrated Wi-Fi 6 and Bluetooth 5.3 provide high-speed wireless connectivity and stable internet for streaming and online gaming.
Triple-display support via HDMI 2.1, DisplayPort 1.2, and D-Sub allows versatile monitor setups for productivity and entertainment.
Dual M.2 PCIe 4.0 slots with RAID functionality offer lightning-fast storage performance and enhanced data redundancy options.
Q-Flash Plus feature allows BIOS updates without needing a CPU, making system maintenance simple and convenient.
Realtek® GbE LAN and Wi-Fi 6 integration deliver low-latency networking for competitive online gaming and large file transfers.
Multiple fan headers and addressable RGB connectors ensure efficient cooling and customizable aesthetics for gaming rigs.
Support for Extreme Memory Profile (XMP) enables automatic overclocking of compatible DDR5 modules for optimal performance.
High-definition audio with Realtek® Audio CODEC supports 7.1-channel surround sound, providing immersive multimedia experiences.
Micro ATX form factor with versatile internal I/O connectors ensures compatibility with most PC cases and future hardware upgrades

GIGABYTE B760M D3HP Motherboard Price in Bangladesh

The GIGABYTE B760M D3HP WIFI6 Micro ATX Motherboard offers premium features at a competitive price in Bangladesh. It is positioned for both performance enthusiasts and mainstream users seeking high-end connectivity, memory support, and graphics capabilities without breaking the budget, making it a cost-effective choice for modern PC builds.

802.11ax Wi-Fi 6

The Wireless solution 802.11ax Wi-Fi 6enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections and speeds up to 2.4Gbps. Moreover, Bluetooth 5.3 provides 4X range over BT 4.2 and with faster transmission.

PCIe 4.0 Hardware Design

Featuring one or multiple PCIe 4.0 x16 slot and PCIe 4.0 M.2 slot support, GIGABYTE Motherboards are ready to work with the PCIe 4.0 devices to provide the superior performance.

Hi-Fi Audio

High-End Audio Capacitors

These high quality capacitors help deliver high resolution and high fidelity audio to provide the most realistic sound effects.

Q-Flash Plus

Update the BIOS easily without installing the CPU, memory, and graphics card.

STEP 1: Plug the 24-pin and 8-pin power supply cables into the motherboard.

STEP 2: Download the motherboard BIOS file and rename it to "gigabyte.bin". Save it to a USB flash drive formatted in FAT32. Insert the USB flash drive into the Q-FLASH PLUS USB port.

STEP 3: Press the Q-FLASH PLUS button, and the motherboard will start updating the BIOS automatically.

Smart Fan 6

ensures optimal cooling and quiet operation for your gaming PC, with support for PWM/DC fans and pumps, customizable settings, and intuitive temperature monitoring.

High Current Support: Each fan headers support PWM and DC fan and Water Cooling Pump , and up to 24W (12V x 2A) with Over-Current Protection.

Precision Control: Multiple temperature/fan speed control points for precise fan curve.

Dual Curve Mode: Slope/Stair dual mode for different user scenario.

Fan Stop: Fan can stop completely below users' specified temperature point.

Smart Fan 6 BIOS UI

Enhance Fan Curve UI : Enhance fan curve control with an expanded number of control points, from 5 to 7, and a larger fan speed graph, enabling users to have more precise and effortless control over fan curve settings.

Slope/Stair Dual Graph Mode : Switch between Slope and Stair modes to adapt to various user scenarios. Slope mode provides a linear fan speed curve, while Stair mode maintains a constant fan speed within specified temperature intervals.

Manual Input : For advanced users, manual input of fan speeds is available for fine-tuning and precise control over the cooling system.

EZ Tuning : Simplify the process with EZ Tuning by setting 4 points on a rough temperature/fan speed scale. Smart Fan 6 will quickly generate a fan curve based on these points.

Fan Curve Profile : Save your customized fan curve profile in the BIOS ROM, ensuring it remains intact even after BIOS updates.

What Makes This Product Special?

Its combination of Wi-Fi 6, high-speed DDR5 memory support, triple-display graphics, and Q-Flash BIOS updates sets it apart. This motherboard delivers unmatched stability, future-ready performance, and advanced customization options for both gamers and professionals.

User Experience OF GIGABYTE B760M D3HP WIFI6 Micro ATX Motherboard

Users enjoy seamless installation, excellent connectivity, and superior multitasking performance. With support for high-speed memory, multiple displays, and enhanced audio, the motherboard ensures smooth gaming, content creation, and everyday computing experiences.

Why Choose This Product from Creatus Computer:

Creatus Computer offers genuine GIGABYTE motherboards with warranty, competitive pricing, and reliable customer support, ensuring peace of mind for buyers seeking high-performance PC components in Bangladesh.
