MSI PRO H610M-E mATX Motherboard
Save: 1480৳ (12%)
MSI PRO H610M-E mATX Motherboard
- Stock: In Stock
- Model: PRO H610M-E
- Product id: 27460
10,400৳
11,880৳
Ex Tax: 10,400৳
- Supported CPU: 14th/13th/12th Gen Intel Processors (LGA1700)
- Supported RAM: 2x DDR5, Max 96GB
- Graphics Output: 1x HDMI, 1x VGA
- Features: 1x M.2 slot, Realtek RTL8111H Gigabit LAN
| Basic Information | |
| Supported CPU | Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron Processors LGA 1700 |
| Chipset | Intel H610 Chipset |
| Form Factor | mATX 200mmx236.16mm |
| Audio | Realtek ALC897 Codec 7.1-Channel High Definition Audio |
| Expansion Slots | |
| PCI | 1x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to (From CPU) PCI_E2 Gen PCIe 3.0 supports up to (From Chipset) |
| Memory | |
| Type | DDR5 |
| Slots | 2 |
| Supported Memory | Memory Support DDR5 5600 MHz (by JEDEC & POR) Supports Intel XMP 3.0 OC Supports Dual-Controller Dual-Channel mode Supports non-ECC, un-buffered memory |
| Maximum Memory | 96GB |
| Graphics | |
| Graphics | Support HDMI 1.4 with HDR, maximum resolution of 4K 30Hz Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| Connector & Ports | |
| HDMI | 1x HDMI 1.4 with HDR port |
| USB (s) | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) |
| LAN Port (s) | Realtek RTL8111H Gigabit LAN |
| Supported Storage | 1x M.2 M.2_1 Source (From Chipset) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G SATA5 will be unavailable when installing M.2 SATA SSD in the M2_1 slot. |
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) |
| Audio | 1x Front panel audio connector |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 1x Power Connector(CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x RGB LED connector(JRGB) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports |
| Others | |
| Special Features | 1x 4-pin RGB LED connector 4x EZ Debug LED |
| Warranty Information | |
| Warranty | 3 years |
MSI pro h610m-e matx motherboard
The MSI PRO H610M-E mATX Motherboard is a dependable and cost-effective solution for users looking to build a stable and efficient system. Designed to support Intel 14th, 13th, and 12th Gen Core processors, along with Pentium Gold and Celeron processors, this motherboard is ideal for office tasks, home computing, and entry-level gaming setups. Equipped with the Intel H610 chipset, the MSI PRO H610M-E ensures seamless performance while providing essential features for modern computing. It supports DDR5 memory with speeds up to 5600 MHz, allowing users to experience faster data transfer and improved multitasking. The motherboard comes with two DIMM slots, offering a maximum memory capacity of 96GB with Intel XMP 3.0 support for better overclocking performance. In terms of expansion, the motherboard includes one PCI-E x16 slot (PCIe 4.0) and one PCI-E x1 slot (PCIe 3.0), making it compatible with a range of GPUs and expansion cards. For graphics output, it features HDMI 1.4 with HDR support (4K @ 30Hz) and a VGA port, ensuring versatile display options. The board also provides ample connectivity, including USB 3.2 Gen1 Type-A ports, USB 2.0 ports, Realtek RTL8111H Gigabit LAN, and high-definition Realtek ALC897 audio codec for an immersive sound experience. Storage options are well-covered with one M.2 slot (PCIe 3.0 x4 / SATA mode) and four SATA 6G ports.
MSI pro h610m-e ddr5
The MSI PRO H610M-E DDR5 motherboard is an excellent for budget-friendly yet powerful PC builds. Designed for 12th and 13th Gen Intel processors, it supports DDR5 memory, ensuring faster speeds and improved efficiency. This mATX motherboard features PCIe Gen 4.0, high-speed connectivity, and core boost technology for stable performance. With M.2 slots, SATA ports, and optimized power design, it offers seamless multitasking and gaming support. The MSI PRO H610M-E DDR5 is perfect for professionals and gamers seeking reliability and affordability in their systems.
MSI pro h610m e matx motherboard price
The MSI PRO H610M-E mATX motherboard is a budget-friendly option for 12th and 13th Gen Intel processors, offering stable performance and essential features. It supports DDR4 memory, ensuring reliable speed and efficiency for daily tasks and office work. With PCIe Gen 4.0 support, M.2 slot, SATA ports, and core boost technology, this motherboard delivers a solid foundation for entry-level and mid-range PC builds. The MSI PRO H610M-E price in Bangladesh varies depending on availability and sellers, typically ranging from BDT 8,000 to BDT 10,000. Whether you’re building a business workstation or a budget gaming rig, this micro-ATX motherboard provides excellent value for money with durability and long-term reliability.
Superior Processor Support
The MSI PRO H610M-E mATX Motherboard is built to accommodate Intel Core 14th, 13th, and 12th Gen processors with an LGA 1700 socket. This compatibility ensures that users can upgrade their system with the latest Intel processors without worrying about motherboard limitations. Whether you need a PC for daily tasks, office work, or casual gaming, this motherboard provides a stable and efficient platform.
High-Speed DDR5 Memory Performance
Memory plays a crucial role in system performance, and this motherboard supports DDR5 RAM with speeds up to 5600 MHz. The dual-channel memory architecture enhances multitasking capabilities, allowing users to run multiple applications smoothly. With a maximum memory capacity of 96GB, the motherboard ensures that users can handle high-performance tasks such as video editing, programming, and light gaming effortlessly.
PCIe 4.0 for Faster Expansion
The MSI PRO H610M-E mATX Motherboard features one PCIe 4.0 x16 slot and one PCIe 3.0 x1 slot, providing excellent expansion options for users. PCIe 4.0 technology offers twice the bandwidth of PCIe 3.0, ensuring faster data transfer speeds for graphics cards and NVMe SSDs. Whether you plan to install a dedicated GPU or additional expansion cards, this motherboard delivers the necessary performance.
Comprehensive Connectivity & Networking
The MSI PRO H610M-E mATX Motherboard is equipped with a range of connectivity options to meet modern computing needs. It includes four USB 2.0 ports (rear), four USB 2.0 ports (front), two USB 3.2 Gen1 Type-A ports (rear), and two USB 3.2 Gen1 Type-A ports (front), ensuring convenient connectivity for peripherals. The motherboard also features HDMI 1.4 with HDR support and VGA output, allowing users to connect high-resolution displays.
Special Features
MSI is known for its high-quality components and durable build, and the MSI PRO H610M-E is no exception. It features EZ Debug LED, making troubleshooting easier for users. The 4-pin RGB LED connector allows users to customize their PC setup with basic lighting effects. The motherboard includes 7.1-channel high-definition audio powered by Realtek ALC897 Codec, ensuring an immersive audio experience.
