ASRock Z690 PG Velocita 12th Gen ATX Motherboard

ASRock Z690 PG Velocita 12th Gen ATX Motherboard

ASRock Z690 PG Velocita Motherboard Supports 12th Gen Intel Core Processors (LGA1700), 17 Phase SPS Dr.MOS Power Design, DDR5 6400MHz (OC), 1 PCIe 5.0 x16, 1 PCIe 4.0 x16, 1 PCIe 3.0 x16, 2 PCIe 3.0 x1, Graphics Output Options: HDMI, DisplayPort, Realtek ALC1220 7.1 CH HD Audio Codec, Nahimic Audio 6 SATA3. This 12th Gen Motherboard comes with 1 Blazing M.2 (PCIe Gen5 x4), 2 Hyper M.2 (PCIe Gen4 x4), 1 Ultra M.2 (PCIe Gen3 x4 & SATA3), 1 USB 3.2 Gen2x2 Front Type-C, 2 USB 3.2 Gen2 (Rear Type A+C) and 10 USB 3.2 Gen1 (6 Rear, 4 Front), Lightning Gaming Ports, Killer E3100 2.5G LAN, Intel Gigabit LAN, Killer AX1675 802.11ax (WiFi 6E) & Bluetooth. The ASRock Z690 PG Velocita featured dual Channel DDR5 Memory Technology, 4 x DDR5 DIMM Slots, Supports DDR5 non-ECC, un-buffered memory up to 6400+(OC), Max. the capacity of system memory: 128GB, Supports Intel Extreme Memory Profile (XMP) 3.0 and 15μ Gold Contact in DIMM Slots. The 12th Gen ASRock Motherboard has 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec), Premium Blu-ray Audio support, Surge Protection, Pure Power-In. It also featured with Direct Drive Technology, PCB Isolate Shielding, Impedance Sensing on Rear Out port, Individual PCB Layers for R/L Audio Channel, Gold Audio Jacks, 15μ Gold Audio Connector and Nahimic Audio. This Latest exclusive High-quality ASRock Z690 PG Velocita Motherboard has 03 years warranty.

ASRock Z690 PG Velocita Review

With the release of Intel's 12th Gen Core processors comes a new socket. This LGA 1700 socket is supported by the Z690 chipset, which also holds the privilege of being the first consumer product to offer both PCIe Gen 5.0 and DDR5 connectivity. ASRock has unleashed a wave of Z690 based motherboards to cover the needs of every type of consumer. From the flagship AQUA OC to ASRock's budget-originated Steel Legend series, there is a motherboard that will be satisfactory. Besides offering native PCIe 5.0 support, the Intel LGA 1700 platform has been given a connection speed boost with a change to the PCH. The DMI 4.0 interface at 16 GT/s is a doubling over DMI 3.0 on the previous LGA 1200 socket. This increased bandwidth not only allows for native USB 3.2 2x2 connectivity, but plenty of storage options as well. AMD also plans to release its own take on DDR5 and PCIe 5.0 with its upcoming AM5 socket to offer customers an alternative when it comes time to retire the old computer. For now though, the only option for the newest technology on the market for consumers is with Intel. It today's review, we will be looking at the Z690 PG Velocita. This motherboard is priced to directly compete with the ASUS Z690 ROG Strix, Gigabyte Z690 AORUS Master, and MSI Z690 MEG Unify, which all offer different configurations for every user. ASRock has a wide range of AMD and Intel motherboards with the Phantom Gaming (PG) line both in the entry and mid-range sectors featuring a dedicated VRM design with seventeen 60 A power stages using an active cooling solution. As expected, the Z690 PG Velocita also includes DDR5 and PCIe 5.0-ready solutions for those looking for the newest technology. ASRock has also added a M.2 Gen5 4x socket for when these next-gen NVMe drives reach the market in late 2022, which is not commonly found on Z690-based motherboards. To round out the experience, the ASRock Z690 PG Velocita also offers great connectivity with the newest WiFi 6E technology and 2.5G LAN for those who need to transfer data quickly. There is a lot to cover in this review, so let's take a closer look at what the ASRock Z690 PG Velocita has to offer.
