MSI PRO Z790-A WIFI DDR4 Intel 12th and 13th Gen ATX Motherboard
Save: 701৳ (2%)
MSI PRO Z790-A WIFI DDR4 Intel 12th and 13th Gen ATX Motherboard
- Stock: In Stock
- Model: Z790-A WIFI DDR4
- Product id: 24001
28,199৳
28,900৳
Ex Tax: 28,199৳
- Supported CPU: 12th/13th Gen Core, Pentium Gold & Celeron Processor (LGA 1700)
- Supported RAM: 4x DDR4, 5333+MHz (OC), Max 128GB
- Graphics Output: 1x HDMI, 1x DisplayPort
- : 2.5G LAN with Wi-Fi 6E Solution
| Key Features | |
| Form Factor | ATX |
| Basic Information | |
| Supported CPU | 12th Gen, 13th Gen |
| Chipset | Z790 |
| General Information | |
| Special Features | USB 3.0 |
| Memory | |
| Ram Type | DDR4 |
Specification
| Basic Information | ||
| Supported CPU | Supports 12th/13th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA 1700 | |
| Chipset | INTEL Z790 | |
| Form Factor | ATX 243.84mmx304.8mm | |
| Audio | Realtek ALC4080 Codec 7.1-Channel USB High Performance Audio Supports S/PDIF output | |
| Expansion Slots | ||
| PCI | 3x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 PCIe 5.0 supports up to x16 (From CPU) PCI_E2 PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 PCIe 4.0 supports up to x4 (From Chipset) PCI_E4 PCIe 3.0 supports up to x1 (From Chipset) | |
| Memory | ||
| Type | DDR4 | |
| Slots | 4 x DIMM | |
| Supported Memory | 5333/ 5200/ 5066/ 5000/ 4800/ 4600/ 4533/ 4400/ 4266/ 4000/ 3866/ 3733/ 3600/ 3466/ 3333(O.C.)/ 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133 (By JEDCE & POR) Max. overclocking frequency: • 1DPC 1R Max speed up to 5333+ MHz • 1DPC 2R Max speed up to 4800+ MHz • 2DPC 1R Max speed up to 4400+ MHz • 2DPC 2R Max speed up to 4000+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP) | |
| Maximum Memory | 128GB | |
| Graphics | ||
| Graphics | 1x HDMI 1x DisplayPort Support HDMI 2.1 with HDR, maximum resolution of 4K 60Hz Support DP 1.4, maximum resolution of 4K 60Hz | |
| Connector & Ports | ||
| HDMI | 1x HDMI | |
| Display Port (s) | 1x DisplayPort | |
| USB (s) | 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) 3x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear) | |
| LAN Port (s) | Intel 2.5Gbps LAN | |
| Wireless Communication module | Intel Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.2, FIPS, FISMA | |
| Supported Storage | 4x M.2 slot M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices M.2_2 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_3 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices M.2_4 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 6x SATA 6G port | |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices | |
| Audio | Audio Connectors | |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 6x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x TBT connector (JTBT, supports RTD3) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 2x USB 3.2 Gen1 Type A 1x USB 3.2 Gen2 Type C | |
| TPM (Trusted Platform Module ) | 1x TPM pin header(Support TPM 2.0) | |
| Others | ||
| Special Features | 4x EZ Debug LED | |
| Warranty Information | ||
| Manufacturing Warranty | 3 years | |
MSI PRO Z790-A WIFI DDR4 Intel 12th and 13th Gen ATX Motherboard
The LGA 1700 processors from the 12th and 13th generation Intel Core, Pentium Gold, and Celeron families are supported by the MSI PRO Z790-A WIFI DDR4 ATX Motherboard. Four DDR4 RAM slots on this ATX motherboard, which uses the Intel Z790 chipset and the LGA 1700 socket, provide twin-channel memory and overclocked speeds of up to 5333 MHz. Ample storage space is provided by six SATA III ports and four M.2 interfaces, which support RAID 0, 1, 5, and 10 via SATA or 0, 1 and 5 via M.2. Through PCIe 5.0 x16, PCIe 4.0 x16, PCIe 3.0 x16, and PCIe 3.0 x1 slots, adapter cards and GPUs can be installed. With a Wi-Fi 6E network and a 2.5 GbE Intel LAN, you may benefit from rapid networking; Bluetooth 5.2 allows you to connect to wireless devices instantly. The back ports can be used for analog or digital output, and the Realtek ALC4080 audio codec provides 7.1 channel surround sound. Connect peripherals through a USB 3.2 Gen 2x2 Type-C port, two USB 2.0, two USB 3.2 Gen 1, and three USB 3.2 Gen 2x2 ports. For video output, DisplayPort and HDMI are employed. On the rear I/O panel, there is also a Flash BIOS button, and internal headers support features including RGB connections, chassis intrusion, a TPM module, front-panel USB 3.2 Gen 2 Type-C and Type-A connectors, and USB 3.2 Gen 1 and 2.0 ports. A three-year guarantee is included with the MSI PRO Z790-A WIFI DDR4 13th Gen ATX Motherboard.Quick Compare
| Product Details | ||||
| Product | MSI PRO Z790-A WIFI DDR4 Intel 12th and 13th Gen ATX Motherboard | MSI B850 GAMING PLUS WIFI7 AM5 ATX Motherboard | GIGABYTE Z790 UD 13th & 12th Gen ATX Motherboard | MSI MAG B650M MORTAR WIFI DDR5 AMD AM5 mATX Motherboard |
| Image | |
|
|
|
| Price | |
|
|
|
| Model | Z790-A WIFI DDR4 | B850 GAMING PLUS WIFI | Z790 UD | B650M MORTAR WIFI |
| Brand | MSI | MSI | GIGABYTE | MSI |
| Availability | In Stock | In Stock | In Stock | In Stock |
| Rating | Based on 0 reviews. |
Based on 0 reviews. |
Based on 0 reviews. |
Based on 0 reviews. |
| Summary | Specification Basic Information Supported CPU Supports 12th/13th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA 1700 Chipset INTEL Z790 Form Factor ATX 243.84mmx304.8mm Audio Realtek ALC4080 Codec 7.1-Channel USB High Performance Audio Supports S/PDIF output Expansion Slots PCI 3x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 PCIe 5.0 supports up to x16 (From CPU) PCI_E2 PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 PCIe 4.0 supports up to x4 (From Chipset) PCI_E4 PCIe 3.0 supports up to x1 (From Chipset) Memory Type DDR4 Slots 4 x DIMM Supported Memory 5333/ 5200/ 5066/ 5000/ 4800/ 4600/ 4533/ 4400/ 4266/ 4000/ 3866/ 3733/ 3600/ 3466/ 3333(O.C.)/ 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133 (By JEDCE & POR) Max. overclocking frequency: • 1DPC 1R Max speed up to 5333+ MHz • 1DPC 2R Max speed up to 4800+ MHz • 2DPC 1R Max speed up to 4400+ MHz • 2DPC 2R Max speed up to 4000+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP) Maximum Memory 128GB Graphics Graphics 1x HDMI 1x DisplayPort Support HDMI 2.1 with HDR, maximum resolution of 4K 60Hz Support DP 1.4, maximum resolution of 4K 60Hz Connector & Ports HDMI 1x HDMI Display Port (s) 1x DisplayPort USB (s) 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) 3x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear) LAN Port (s) Intel 2.5Gbps LAN Wireless Communication module Intel Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.2, FIPS, FISMA Supported Storage 4x M.2 slot M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices M.2_2 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_3 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices M.2_4 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 6x SATA 6G port RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices Audio Audio Connectors Internal I/O Ports 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 6x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x TBT connector (JTBT, supports RTD3) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 2x USB 3.2 Gen1 Type A 1x USB 3.2 Gen2 Type C TPM (Trusted Platform Module ) 1x TPM pin header(Support TPM 2.0) Others Special Features 4x EZ Debug LED Warranty Information Manufacturing Warranty 3 years MSI PRO Z790-A WIFI DDR4 Intel 12th and 13th Gen ATX Motherboard The LGA 1700 processors from the 12th and 13th generation Intel Core, Pentium Gold, and Celeron families are supported by the MSI PRO Z790-A WIFI DDR4 ATX Motherboard. Four DDR4 RAM slots on this ATX motherboard, which uses the Intel Z790 chipset and the LGA 1700 socket, provide twin-channel memory and overclocked speeds of up to 5333 MHz. Ample storage space is provided by six SATA III ports and four M.2 interfaces, which support RAID 0, 1, 5, and 10 via SATA or 0, 1 and 5 via M.2. Through PCIe 5.0 x16, PCIe 4.0 x16, PCIe 3.0 x16, and PCIe 3.0 x1 slots, adapter cards and GPUs can be installed. With a Wi-Fi 6E network and a 2.5 GbE Intel LAN, you may benefit from rapid networking; Bluetooth 5.2 allows you to connect to wireless devices instantly. The back ports can be used for analog or digital output, and the Realtek ALC4080 audio codec provides 7.1 channel surround sound. Connect peripherals through a USB 3.2 Gen 2x2 Type-C port, two USB 2.0, two USB 3.2 Gen 1, and three USB 3.2 Gen 2x2 ports. For video output, DisplayPort and HDMI are employed. On the rear I/O panel, there is also a Flash BIOS button, and internal headers support features including RGB connections, chassis intrusion, a TPM module, front-panel USB 3.2 Gen 2 Type-C and Type-A connectors, and USB 3.2 Gen 1 and 2.0 ports. A three-year guarantee is included with the MSI PRO Z790-A WIFI DDR4 13th Gen ATX Motherboard. .. | MSI B850 GAMING PLUS WIFI7 AM5 ATX Motherboard in Bangladesh The MSI B850 GAMING PLUS WIFI7 AM5 ATX Motherboard is designed for gamers, content creators, professionals, and PC enthusiasts who want reliable next-generation performance. Built on the advanced AMD B850 chipset, this motherboard supports AMD Ryzen 9000, 8000, and 7000 Series processors, making it an ideal foundation for high-performance gaming systems and productivity workstations.Whether you are building a new PC or upgrading an existing AM5 platform, this motherboard offers the latest technologies including DDR5 memory support, PCIe 5.0 expansion, Wi-Fi 7 connectivity, 5G LAN networking, and high-speed storage options. For users in Bangladesh seeking a future-ready motherboard that balances performance, features, and value, the MSI B850 GAMING PLUS WIFI7 stands out as an excellent choice. Built for AMD Ryzen AM5 Processors The motherboard supports AMD Ryzen 9000, 8000, and 7000 Series desktop processors through the AM5 socket platform. This ensures compatibility with some of AMD's most powerful CPUs, allowing users to build gaming PCs capable of handling demanding AAA games, streaming workloads, professional software, and multitasking environments.For gamers in Bangladesh who want long-term upgrade flexibility, the AM5 platform provides an excellent investment. Users can start with a mid-range processor and upgrade later without changing the motherboard. Ultra-Fast DDR5 Memory Support Memory performance plays a major role in gaming and productivity, and MSI has equipped this motherboard with four DDR5 DIMM slots supporting up to 256GB memory capacity. The board supports memory overclocking speeds up to 8200+ MT/s, delivering outstanding responsiveness and faster application performance.Whether you are editing videos, running virtual machines, creating 3D designs, or playing competitive esports titles, the advanced DDR5 memory architecture helps ensure smoother performance and lower latency. PCIe 5.0 for Maximum Graphics Performance The MSI B850 GAMING PLUS WIFI7 features a PCIe 5.0 x16 primary slot, providing exceptional bandwidth for modern graphics cards. This enables gamers to take full advantage of high-end GPUs and prepares the system for future graphics upgrades.Users building powerful gaming rigs for 1440p or 4K gaming can confidently pair this motherboard with the latest graphics cards while maintaining optimal performance and stability. Next-Generation Storage Support Storage speed significantly impacts overall system responsiveness. This motherboard includes three M.2 slots and four SATA ports, giving users flexible storage options for gaming libraries, content creation projects, and business data.The primary M.2 slot supports PCIe 5.0 x4 NVMe SSDs, delivering blazing-fast read and write speeds. Additional PCIe 4.0 M.2 slots provide ample room for expanding storage capacity without sacrificing performance.Users who frequently transfer large files, edit high-resolution videos, or run demanding applications will appreciate the high-speed storage architecture offered by this motherboard. Advanced Wi-Fi 7 and Bluetooth 5.4 Connectivity One of the standout features of the MSI B850 GAMING PLUS WIFI7 motherboard is its built-in Wi-Fi 7 solution. Wi-Fi 7 provides significantly improved wireless speeds, lower latency, and enhanced network stability compared to previous generations.For Bangladeshi users who rely on wireless internet connections, Wi-Fi 7 helps improve online gaming experiences, video conferencing quality, cloud computing access, and high-speed downloads.The integrated Bluetooth 5.4 support also allows seamless connectivity with wireless headphones, keyboards, mice, controllers, and other compatible devices. High-Speed 5G LAN Networking In addition to wireless connectivity, the motherboard includes a Realtek 8126VB 5G Ethernet controller. This high-speed wired networking solution is ideal for competitive gamers, streamers, and professionals who require maximum network stability and low latency.Whether you are participating in online tournaments, streaming content, or transferring large files across a local network, the 5G LAN connection delivers reliable performance. Immersive Audio Experience The MSI B850 GAMING PLUS WIFI7 utilizes the Realtek ALC897 audio codec with support for 7.1-channel High Definition Audio. This provides rich sound quality for gaming, movies, music, and professional multimedia applications.Gamers can enjoy better positional awareness during competitive gameplay, while content consumers benefit from more immersive audio experiences. Comprehensive USB Connectivity Modern users often connect multiple devices simultaneously, and MSI addresses this requirement with a wide range of USB connectivity options. The motherboard offers USB 10Gbps Type-A and Type-C ports, USB 5Gbps ports, and additional front-panel connectivity.This allows convenient connection of external SSDs, gaming peripherals, smartphones, capture cards, printers, and other accessories without bandwidth limitations. Designed for Easy Building and Maintenance MSI has integrated several user-friendly features that simplify system assembly and maintenance. The Flash BIOS Button allows BIOS updates without requiring a processor installation, while EZ Debug LEDs help quickly identify hardware issues during system setup.These features are particularly beneficial for first-time PC builders and users upgrading their systems independently. RGB Customization and Cooling Support The motherboard includes multiple RGB and ARGB headers, enabling users to create visually impressive gaming setups. Whether you prefer subtle lighting or a fully synchronized RGB ecosystem, the board offers extensive customization possibilities.It also provides multiple fan headers and pump support, allowing users to build efficient cooling solutions for gaming, rendering, and workstation applications. Why Buy MSI B850 GAMING PLUS WIFI7 from Creatus? When purchasing premium PC components in Bangladesh, authenticity and after-sales support are important considerations. Creatus provides genuine MSI products backed by official manufacturer warranty coverage, helping customers shop with confidence.Customers choosing Creatus benefit from competitive pricing, reliable service, secure ordering, and professional support for building high-performance gaming and productivity systems.If you are searching for a future-ready AM5 motherboard that delivers excellent connectivity, high-speed storage, advanced networking, and strong upgrade potential, the MSI B850 GAMING PLUS WIFI7 AM5 ATX Motherboard is a smart investment. Available from Creatus, this motherboard is well-suited for gamers, creators, professionals, and PC enthusiasts throughout Bangladesh.Whether your goal is competitive gaming, content creation, software development, or building a premium workstation, Creatus offers this MSI motherboard as a dependable platform capable of supporting your computing needs for years to come. Frequently Asked Questions (FAQs) 1. What is the warranty period for the MSI B850 GAMING PLUS WIFI7 motherboard? The MSI B850 GAMING PLUS WIFI7 AM5 ATX Motherboard comes with a 3-year manufacturer warranty, ensuring peace of mind and long-term reliability. 2. Does this motherboard support AMD Ryzen 9000 Series processors? Yes, the motherboard supports AMD Ryzen 9000, 8000, and 7000 Series desktop processors through the AM5 socket platform. 3. Is Wi-Fi 7 built into the motherboard? Yes, the motherboard includes built-in Wi-Fi 7 and Bluetooth 5.4 support, providing high-speed wireless connectivity without requiring additional adapters... | Specification Basic Information Supported CPU LGA1700 socket: Support for the 13th and 12th Generation Intel Core, Pentium Gold and Celeron Processors L3 cache varies with CPU Chipset Intel Z790 Express Chipset BIOS 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Form Factor ATX Form Factor; 30.5cm x 24.4cm Audio Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out Expansion Slots PCI CPU: 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4) 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1_4) 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_2, PCIEX1_3) Support for AMD CrossFire technology (PCIEX16 and PCIEX4) Memory Type DDR5 Slots 4 x DIMM sockets Supported Memory 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules Maximum Memory 128GB (32 GB single DIMM capacity) Graphics Graphics Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.0 version and HDCP 2.3. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 1.2 version and HDCP 2.3 Connector & Ports HDMI 1 x HDMI Display Port (s) 1 x DisplayPort USB (s) Chipset: 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2x2 support 1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB header 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) Chipset+2 USB 2.0 Hubs: 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) LAN Port (s) Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) Supported Storage CPU: 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: 2 x M.2 connectors (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB, M2P_SB) 6 x SATA 6Gb/s connectors RAID RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices Audio 3 x audio jacks Internal I/O Ports 1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x water cooling CPU fan header 3 x system fan headers 1 x system fan/water cooling pump header 2 x addressable LED strip headers 2 x RGB LED strip headers 3 x M.2 Socket 3 connectors 6 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB Type-C header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x serial port header 2 x Thunderbolt add-in card connectors 1 x reset button 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper TPM (Trusted Platform Module ) 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) Others Special Features Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup Bundled Software Norton Internet Security (OEM version) LAN bandwidth management software Warranty Information Manufacturing Warranty 3 years GIGABYTE Z790 UD 13th & 12th Gen ATX Motherboard The GIGABYTE Z790 UD ATX Motherboard comes with Intel Socket LGA 1700 that supports 13th and 12th Gen Series Processors. It delivers unparalleled performance with twin 16+1+1 Phases Digital VRM Solution. The motherboard comes with 4x SMD DIMMs with XMP 3.0 Memory Module Support. The sockets support up to 128 GB (32 GB single DIMM capacity) of system memory. The motherboard is equipped with 3x PCIe 4.0 x4 M.2 Connectors. It supports new PCIe 5.0 SSD with up to type 25110 M.2 slot designed to provide high power M.2 PCIe 5.0 SSD solutions. It has PCIe 5.0 x16 Slot with Quick Release & Screwless Design. The GIGABYTE Z790 UD is equipped with a 2.5GbE LAN that provides up to 2.5 GbE network connectivity, with at least 2 times faster transfer speeds compared to general 1GbE networking, perfectly designed for gamers with ultimate online gaming experience. The advanced cooling solution also provides the perfect aesthetic heatsink design to keep your PC at an optimal temperature, preventing you from unexpected system crashes during the creative process. The GIGABYTE Z790 UD ATX Motherboard comes with 3 years of warranty. .. | Unleash Extreme Performance with MSI MAG B650M MORTAR WIFI AMD AM5 MotherboardThe AMD Ryzen 7000-series CPUs with up to 16 Zen 4 cores and dual-channel DDR5 memory with a maximum memory capacity of up to 128GB and a bus speed of up to 6400+(OC) MHz are supported by the MSI MAG B650M MORTAR WIFI Motherboard. It has a dual 8-pin CPU power connector, a 12+2+1 Duet Rail Power System, Core Boost, and Memory Boost. It is designed for a high-performance system and a nonstop gaming experience and includes an expanded heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads, and a double-sided M.2 Shield Frozr. The motherboard is constructed from an 8-layer PCB comprised of server-grade materials and copper that is 2 oz thicker. With PCIe 4.0 slots, Lightning Gen 5 x4 M.2, and USB 3.2 Gen 2x2, it can give a lightning-fast gaming experience. The double-sided Shield Frozr architecture makes M.2 SSDs quicker while keeping them safe and reducing throttling. The rear I/O panel now provides quick access to Turbo mode, a one-click toggle for all RGB lights, and direct safe boot entry. Built-in USB 3.2 Gen 2x2 port; 20 Gbps transmission speed; 4X quicker than USB 3.2 Gen 1; available on the MSI MAG B650M MORTAR WIFI DDR5 AMD AM5 mATX Motherboard. When using the rear USB Type-C, the MAG B650 series motherboards provide never-before-seen USB speeds of up to 20 Gb/s, giving you a wide range of options for connecting and enhancing your USB devices. With PCIe 4.0 slots, Lightning Gen 5 x4 M.2, and USB 3.2 Gen 2x2, it can give a lightning-fast gaming experience.DDR5 Memory Support for Higher PerformanceThis motherboard supports DDR5 memory with speeds of up to 6400+ MHz (OC). It comes with 4 DIMM slots and supports up to 128GB of memory. DDR5 not only improves data bandwidth but also enhances system responsiveness, making multitasking and high-demand applications much smoother.Dual M.2 and SATA Storage OptionsStorage flexibility is a highlight here, thanks to two M.2 slots (PCIe 4.0 x4) and six SATA 6 Gbps ports. The M.2 slots support 2280/2260 devices and allow for ultra-fast NVMe SSD performance. RAID support is included for both M.2 and SATA configurations, ensuring redundancy and performance optimization.Next-Gen Wireless and NetworkingStay connected with Realtek RTL8125B 2.5 Gbps LAN for high-speed wired connections, ideal for competitive online gaming. For wireless freedom, the board comes with Wi-Fi 6E support via a pre-installed module in the M.2 (Key-E) slot. It also supports Bluetooth 5.2, MU-MIMO, and 6GHz band operation for smooth streaming, downloads, and multitasking.Superior Audio ExperienceThe Realtek ALC4080 audio codec provides 7.1-channel high-definition audio. It supports 32-bit/384 kHz playback, offering rich and immersive sound quality, especially useful for gamers, content creators, and media enthusiasts. The board also supports S/PDIF output for digital audio connections.Features of MSI MAG B650M MORTAR WIFI DDR5 MotherboardSupports Latest AMD Ryzen Processors: Compatible with AMD Ryzen 9000, 8000, and 7000 Series Desktop CPUs on the AM5 socket, offering future-ready performance and upgrade flexibility.Next-Gen DDR5 Memory Support: Equipped with 4 DDR5 DIMM slots supporting up to 128GB RAM and speeds up to 6400+ MHz (OC) for superior multitasking and gaming performance.Advanced Power Design: Features a robust 12+2+1 Duet Rail Power System, dual 8-pin CPU connectors, and Core Boost technology for stable, high-performance power delivery.Lightning-Fast Storage & Expansion: Includes 2x PCIe 4.0 x16 slots, 2x M.2 Gen4 x4 slots with Double-sided M.2 Shield Frozr, and 6x SATA 6Gb/s ports supporting RAID 0/1/10 for flexible, high-speed storage.Wi-Fi 6E & 2.5G LAN for Superior Connectivity: Offers AMD Wi-Fi 6E (802.11ax) with Bluetooth 5.2 and Realtek RTL8125B 2.5Gbps LAN for ultra-fast, stable wired and wireless connections.High-Definition Audio Experience: Powered by Realtek ALC4080 codec, it delivers 7.1-channel HD audio with S/PDIF out and up to 32-bit/384 kHz playback for immersive sound quality.Comprehensive USB Support: Offers extensive connectivity with USB 3.2 Gen 2x2 Type-C (20Gbps), USB 3.2 Gen 2 and Gen 1 ports, and USB 2.0—perfect for peripherals and fast data transfers.MSI MAG B650M MORTAR WIFI price in BDThe MSI MAG B650M MORTAR WIFI is a high-performance motherboard designed for AMD Ryzen 7000, 8000, and 9000 series processors, featuring DDR5 memory support, Wi-Fi 6E, and PCIe 4.0 slots. It offers exceptional stability, advanced connectivity, and reliable cooling in a compact mATX form factor. Ideal for gamers and PC enthusiasts, this motherboard ensures seamless performance and future-proofing. If you're planning a next-gen AMD build, it's a top choice. As of now, the MSI MAG B650M MORTAR WIFI price in BD varies depending on the retailer, but it typically ranges between BDT 22,000 to BDT 29,000... |
|
|
|
|
|
|
