MSI MAG B860 TOMAHAWK WIFI DDR5 ATX Motherboard

Save: 1601৳ (5%)

MSI MAG B860 TOMAHAWK WIFI DDR5 ATX Motherboard

Stock: In Stock
Model: MAG B860 TOMAHAWK WIFI
Product id: 27633

Based on 0 reviews. - Write a review

33,399৳

35,000৳

Ex Tax: 33,399৳

EMI starts at 11,712৳/month. View all 25 banks EMI plans >

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

* অনলাইনে প্রোডাক্ট অর্ডারের পূর্বে আমাদের হেল্পলাইন +8801612-266507 নম্বরে কল দিয়ে স্টক এবং ডেলিভারী সর্ম্পকে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা যাচ্ছে *

Supported CPU: Intel Core Ultra Processors (Series 2), LGA 1851
Supported RAM: 4x DDR5, Dual Channel 9200+ MT/s (OC), Max 256GB
Graphics Output: 1x HDMI, 1x DisplayPort, 1x Type-C DisplayPort
Features: 3x M.2 Slot, 1x 5Gbps LAN, Intel Killer Wi-Fi 7, Bluetooth 5.4

Basic Information
Supported CPU	Supports Intel Core Ultra Processors (Series 2) LGA 1851
Chipset	INTEL B860
Form Factor	ATX 243.84mmx304.8mm
Audio	Realtek ALC897 Codec 7.1-Channel High Definition Audio Supports S/PDIF output
General Information
Memory Type	DDR5
Expansion Slots
PCI	2x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
M.2 Socket	3x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
Memory
Slots	4x UDIMM
Supported Memory	Memory Support 9200 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s Max. overclocking frequency: • 1DPC 1R Max speed up to 9200+ MT/s • 1DPC 2R Max speed up to 7200+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 5600+ MT/s Supports Intel® POR Speed and JEDEC Speed Supports Memory Overclocking and Intel® XMP 3.0 Supports Dual-Controller Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM
Maximum Memory	256GB
Graphics
Graphics	1x HDMI Support HDMI 2.1 with FRL, maximum resolution of 8K 60Hz 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz 1x Type-C DisplayPort Thunderbolt 4 ports, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz
Connector & Ports
HDMI	1x HDMI 2.1 with FRL
Display Port (s)	1x DisplayPort 1.4 1x Type-C DisplayPort Thunderbolt 4 ports, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz
USB (s)	4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Front) 4x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear) 1x USB 10Gbps Type C (Front) 1x USB 40Gbps Type C (Rear)
Wireless Communication module	Intel Killer BE1750x Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth 5.4, MLO, 4KQAM
Supported Storage	3x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices 4x SATA 6G
RAID	Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Audio	1x Front Audio (JAUD)
Others
Special Features	4x EZ Debug LED 1x EZ Memory Detection LED
Warranty Information
Warranty	3 Year

MSI MAG B860 TOMAHAWK WIFI DDR5 ATX Motherboard

MSI MAG B860 TOMAHAWK WIFI DDR5 ATX Motherboard is a high-performance solution tailored for gamers and professionals looking to unlock the full potential of modern computing. Built on the Intel B860 chipset and supporting Intel Core Ultra Processors (Series 2), this motherboard ensures seamless performance and compatibility with cutting-edge CPUs. With its ATX form factor, it offers ample space for robust hardware configurations while maintaining excellent build quality and aesthetics.Featuring support for DDR5 memory, the MAG B860 TOMAHAWK allows up to 256GB of RAM, enabling ultra-fast data transfer rates with overclocked speeds of up to 9200 MT/s. Dual-Controller Dual-Channel mode and Intel® XMP 3.0 support ensure optimized performance for memory-intensive tasks. The motherboard’s PCIe 5.0 and PCIe 4.0 slots provide robust expandability for graphics cards and other components, ensuring superior gaming and productivity experiences.Storage options are plentiful with three M.2 slots (supporting PCIe 5.0 and 4.0) and four SATA 6G ports, offering versatile configurations for lightning-fast NVMe SSDs and traditional drives. The built-in Intel Killer BE1750x Wi-Fi 7 ensures reliable wireless connectivity with ultra-high-speed internet access, while the Intel Killer E5000 5Gbps LAN port caters to wired connections. Bluetooth 5.4 compatibility adds further versatility for peripheral devices.The MAG B860 TOMAHAWK supports stunning visuals with HDMI 2.1, DisplayPort 1.4, and Thunderbolt 4 Type-C DisplayPort, enabling resolutions up to 8K at 60Hz or 4K at 120Hz. With enhanced audio provided by the Realtek ALC897 Codec and 7.1-Channel HD Audio, this motherboard ensures an immersive multimedia experience.Designed for durability and ease of use, it includes EZ Debug LEDs, Addressable RGB connectors, and comprehensive I/O options. With a 3-year warranty, the MSI MAG B860 TOMAHAWK WIFI DDR5 ATX Motherboard is an excellent choice for enthusiasts seeking performance, flexibility, and reliability.

Features

Supports Intel Core Ultra Processors (Series 2) with LGA 1851 socket.
Equipped with DDR5 memory slots, supporting up to 256GB and speeds of up to 9200 MT/s (OC).
Three M.2 slots supporting PCIe 5.0 and PCIe 4.0 for ultra-fast storage solutions.
Intel Killer BE1750x Wi-Fi 7 for high-speed wireless connectivity and Intel Killer E5000 5Gbps LAN for reliable wired connections.
Advanced display outputs: HDMI 2.1, DisplayPort 1.4, and Thunderbolt 4 Type-C DisplayPort supporting up to 8K resolution.
EZ Debug LEDs and Addressable RGB connectors for simplified troubleshooting and aesthetic customization.
