GIGABYTE B365M AORUS ELITE INTEL MOTHERBOARD

Name: GIGABYTE B365M AORUS ELITE INTEL MOTHERBOARD
Brand: GIGABYTE
Availability: OutOfStock

Out Of Stock

GIGABYTE B365M AORUS ELITE INTEL MOTHERBOARD

Stock: Out Of Stock
Model: GIGABYTE B365M AORUS
Product id: 19215

Based on 0 reviews. - Write a review

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

* অনলাইনে প্রোডাক্ট অর্ডারের পূর্বে হেল্পলাইন থেকে স্টক এবং ডেলিভারী সর্ম্পকে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা যাচ্ছে *

• Supports 9th and 8th Gen Intel Core Processors • CEC 2019 ready • Dual BIOS • Anti-Sulfur Resistor

GIGABYTE B365M AORUS ELITE INTEL MOTHERBOARD

Gigabyte B365 M AORUS ELITE is an Intel B365 Express Chipset based device. It supports 9th and 8th Generation Intel Core i9 processors, Intel Core i7 processors, Intel Core i5 processor, Intel Core i3 processors, Intel Pentium processors and Intel Celeron processors in the LGA1151 package. Gigabyte Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential. It built with dual M.2 slots. This configuration is designed for flexibility and adaptation to fit most users' and gamers' requests. Intel GbE LAN features cFosSpeed, a network traffic management application which helps to improve network latency and maintain low ping times to deliver better responsiveness in crowded LAN environments. GIGABYTE motherboards use ICs with up to 3 times the ESD resistance levels compared to traditional ICs. This helps to better protect the motherboard and its components against potential damage caused by static electricity. GIGABYTE motherboards also feature special anti-surge ICs that protect your motherboard, and your PC from any surge in power delivery that may occur, helping to ensure that your PC is equipped to deal with any potentially irregular and inconsistent power delivery. With AORUS Motherboards, RGB Fusion 2.0 is even better with Addressable LEDs.* RGB Fusion 2.0 offers users the option to control on-board RGB and external RGB / Addressable LED light strips for their PC. Already feature filled with colors and patterns, RGB Fusion 2.0 on B360 Series AORUS Motherboards are now upgraded with Addressable LED support.

Specification:

Basic Information
Supported CPU	Support for 9th and 8th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1151 package
Chipset	Intel B365 Express Chipset
BIOS	2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for DualBIOS™ PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	Micro ATX Form Factor; 24.4cm x 24.4cm
Expansion Slots
PCI	1 x PCI Express x16 slot, running at x16 (PCIEX16) - For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x16 slot, running at x4 (PCIEX4) 1 x PCI Express x1 slot - (All of the PCI Express slots conform to PCI Express 3.0 standard.)
M.2 Socket	1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI)
Memory
Type	DDR4
Slots	4
Supported Memory	DDR4 2666/2400/2133 MHz memory modules
Maximum Mamory	64GB
Graphics
Graphics	1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz - The DVI-D port does not support D-Sub connection by adapter. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz - Support for DisplayPort 1.2 version, HDCP 2.2, and HDR. 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz - Support for HDMI 1.4 version and HDCP 2.2.
Max Shared Memory	1 GB
Connector & Ports
HDMI	Yes ( 1 x HDMI port )
Display Port (s)	Yes ( 1 x Display Port )
USB (s)	1 x USB Type-C port on the back panel, with USB 3.1 Gen 1 support 5 x USB 3.1 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
LAN Port (s)	Intel GbE LAN chip (10/100/1000 Mbit)
Supported Storage	1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 PCIe x4/x2 SSD support) (M2Q) 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2A) 6 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, RAID 5, and RAID 10 Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
Audio	Realtek ALC892 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 3 x system fan headers 2 x addressable LED strip headers 2 x addressable LED strip power select jumpers 2 x RGB LED strip headers 6 x SATA 6Gb/s connectors 2 x M.2 Socket 3 connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB 3.1 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x serial port header 1 x Clear CMOS jumper
D-Sub (s)	No
DVI-D (s)	Yes ( 1 x DVI-D port )
Warranty Information
Manufacturing Warranty	03 Year Warranty
