| Summary |
Type- Dome Camera
Image Sensor- 1/3 CMOS
Electronic Shutter Speed- PAL: 1/25~1/100000s NTSC: 1/30~1/100000s
Minimum Illumination- 0.02Lux/F2.0, 0Lux IR on
Video Detection- Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering
IR On/Off Control Auto / Manual
Power Consumption Max 2.8W (12V DC, IR on)
.. |
HikVision DS-2CE10DF0T-F 2MP ColorVu Fixed Mini Bullet Camera
HikVision DS-2CE10DF0T-F 2MP ColorVu Fixed Mini Bullet Camera featured with High quality imaging with 2 MP, 1920 × 1080 resolution, 24/7 color imaging with F1.0 aperture, 3D DNR technology delivers clean and sharp images, 2.8 mm, 3.6 mm, 6 mmfixed focal lens, Water and dust resistant (IP67) & Up to 20 m white light distance for bright night imaging. It is also has One port for four switchable signals (TVI/AHD/CVI/CVBS).
This new HikVision DS-2CE10DF0T-F 2MP ColorVu Fixed Mini Bullet Camera has 01 year warranty.
Specifications
General
Pan/Tilt/Rotation
Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
Camera
Image Sensor
2 MP CMOS
Electronic Shutter Speed
PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Minimum Illumination
0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
IR Distance
Up to 20 m white light distance for bright night imaging
Lens
Mount Type
M12
Focal Length
2.8 mm, 3.6 mm, 6 mmfixed focal lens
Max Aperture
24/7 color imaging with F1.0 aperture
Angle of View
Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
Video
Resolution
1920 (H) × 1080 (V)
Frame Rate
TVI: 1080p@25fps/30fps
CVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVBS: PAL/NTSC
Day/Night
Up to 20 m white light distance for bright night imaging
Warranty
Warranty
01 year warranty
.. |
Hikvision DS-2CE11D0T-PIRL 2MP PIR Fixed Mini Bullet Camera
Hikvision DS-2CE11D0T-PIRL 2MP PIR Fixed Mini Bullet Camera featured with 2 MP PIR bullet camera, PIR detection and strobe light alarm to warn off intruders in real-time, EXIR 2.0: advanced infrared technology with 20 m IR distance & Water and dust resistance (IP67). This Mini Bullet Camera comes with 2.0-megapixel progressive scan CMOS Image Sensor, 1920 (H) × 1080 (V) Max. Resolution, Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR, PAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s Shutter Time. It has IR cut filter Day & Night. Pan: 0° to 360°, Tilt: 0° to 180°, Rotate: 0° to 360° Angle Adjustment with PAL/NTSC Signal System are also available in this Mini Bullet Camera. The latest Hikvision DS-2CE11D0T-PIRL 2MP PIR Fixed Mini Bullet Camera has 01-year warranty.
Specification
General
Dimensions
68 mm × 70 mm × 179.8 mm ( 2.68" × 2.76" × 7.08" )
Weight
Approx. 345 g (0.76 lb.)
Pan/Tilt/Rotation
Pan: 0°to 360°,
Tilt: 0°to 180°,
Rotate: 0°to 360°
Operating Conditions
40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing)
Power Supply
12 VDC±25%
Camera
Image Sensor
2.0 megapixel progressive scan CMOS
Electronic Shutter Speed
PAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s
Minimum Illumination
Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
IR Distance
20m
IR On/Off Control
PIR detection and strobe light alarm to warn off intruders in real time
Lens
Lens Type
2.8 mm, 3.6 mm fixed focal lens
Mount Type
M12
Angle of View
Angle: 110°, Range:11 m
Close Focus Distance
20 m IR distance
Video
Resolution
1920 × 1080 resolution
Frame Rate
PAL: 1080p@25fps
NTSC: 1080p@30fps
Video Output
HD analog output
Day/Night
IR cut filter
Interface
Video Interface
Video Output 1 HD analog output
Warranty
Warranty
01 year warranty
.. |
HikVision DS-2CE16D0T-IT5F 2MP EXIR Bullet Camera
HikVision DS-2CE16D0T-IT5F 2MP EXIR Bullet Camera comes with 2 Megapixel high-performance CMOS Analog HD output, up to 1080P resolution, True Day/Night, Smart IR, EXIR technology, up to 20m/40m/80m IR distance, IP66 weatherproof & Switchable TVI/ AHD/ CVI/ CVBS. This Bullet Camera featured with Pan: 0°-360°; Tilt:0°-180°; Rotation: 0°-360°, IR cut filter with auto switch, 1/25(1/30) s to 1/50,000 s Shutter Time & 1920(H) x 1080(V).
The new HikVision DS-2CE16D0T-IT5F 2MP EXIR Bullet Camera has 01 year warranty.
Specifications
General
Dimensions
86.7 mm × 81.6 mm × 226 mm(3.4" × 3.2" × 8.9")
Weight
430 g (0.95 lb)
Pan/Tilt/Rotation
Pan: 0°-360°; Tilt:0°-180°; Rotation: 0°-360°
Operating Conditions
-40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing)
Power Supply
12 VDC±15%
Power Consumption
Max. 6W
Camera
Image Sensor
2MP CMOS Image Sensor
Effective Pixels
1920(H) x 1080(V)
Electronic Shutter Speed
1/25(1/30) s to 1/50,000 s
Minimum Illumination
0.01 Lux @ (F1.2,AGC ON),0 Lux with IR
S/N Ratio
More than 62 dB
IR Distance
up to 20m/40m/80m IR distance
Lens
Mount Type
M12
Video
Resolution
1920(H) x 1080(V)
Frame Rate
1080p@25fps/1080p@30fps
Video Output
1 Analog HD output
Day/Night
True Day/Night IR cut filter with auto switch
Warranty
Warranty
01 year warranty
.. |
